Manual Door Passenger Elevator

Get a Price/Quote

MOQ : 1 Unit

Manual Door Passenger Elevator Specification

Car Dimension
Approx. 1100mm x 1400mm

Door Opening Size
800mm

Pit Depth
1500 mm

Load Capacity
320-1000 kg

Voltage
220V/380V

Noise Level
<60 dB

Hoist Way Size
1800mm x 1500mm

Overhead Height
4000 mm

Inclination
Vertical only

Machine Room Size
2200mm x 1800mm

Type
Manual Door Passenger Elevator

Usage
Residential, Commercial Buildings

Material
Stainless steel cabin, mild steel frame

Drive Type
Geared/gearless traction

Power Supply
Three Phase AC

Speed
1.0 m/s

Max. Lifting Height
Up to 40 meters

Max. Lifting Weight
1000 kg

Mechanism Type
Manual Door

Working Temperature
0C to 40C

Control Device
Microprocessor based control panel

Safety Device
Overload protection, emergency alarm, auto rescue device

Capacity
4-10 Persons

Operation
Simple push button

Communication
Intercom/telephone provision

Door Sensor
Infrared sensor (optional)

Power Backup
Optional with UPS

Door Type
Manual swing door

Max Stops
Up to 15 floors

Emergency Stop Button
Available

Maintenance Required
Periodic lubrication and inspection

Maximum Travel Distance
Up to 40 m

Cabin Finish
Hairline stainless steel/painted MS

Auto Leveling
Provided

Floor Display
Digital LED/LCD display

Lighting
LED cabin lighting

Guide Rail Material
Solid steel

Manual Door Passenger Elevator Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
50 Units, , Per Month

Delivery Time
1 Week

About Manual Door Passenger Elevator

Provided Manual Door Passenger Elevator deserves praise for its adequate load bearing capacity and smooth operation. This elevator can transport 5 to 13 persons simultaneously. It comprises of collapsible swing door, machine room and platform edge with 340 kg to 884 kg weight range. This Manual Door Passenger Elevator is appreciated for its reliable operation, consistent performance, ergonomic look and standard safety features. Its quality has been tested on the basis of its design, diameter, life span, lifting speed etc.

Manual Door Operation Passenger Elevators:

Load	Platform Edges	Lift-Well in Side Finished	Entrance Width	Door Type	Machine Room	-	-	-	-
Sons Per	KG	A	B	C	D	E	-	K	L
5	340	950	1300	1350	1650	760	Collapsible Swing Imperforate	600 C 600	300 D 1500
5	340	1300	1000	1700	1300	760		300 C 300	600 D 1500
6	408	1200	Speed MPS	PIT Depth	Over Head	800		300 C 300	600 D 1500
8	544	1500	Upto 0.68	1600	4900	800		300 C 300	600 D 1500
13	884	1900	1500	2400	1850	900		600 C 600	300 D 1500

Speed MPS	PIT Depth	Over Head
Upto 0.68	1600	4900

Advanced Safety and Control Features

Safety is a priority with included emergency alarm, overload protection, and an auto rescue device. The microprocessor-based control panel ensures precise and reliable elevator movement. Infrared sensors for the door and power backup with UPS are available as optional upgrades for enhanced safety and continuity.

Flexible Design for Modern Spaces

Suitable for both residential and commercial buildings, this elevator complements various architectural needs. Its customizable cabin finishing-hairline stainless steel or painted mild steel-pairs with LED cabin lighting for an elegant, energy-efficient interior. Multiple capacity options and machine room configurations are available to suit diverse installation requirements.

User-Friendly Operation and Maintenance

The simple push-button operation makes the elevator accessible to all users, while digital displays provide clear floor information. Routine maintenance involves periodic lubrication and inspection, ensuring long-term reliability. Communication options like intercom or telephone provisions enhance safety during emergencies.

FAQ's of Manual Door Passenger Elevator:

Q: How does the manual swing door mechanism function on this passenger elevator?

A: The manual swing door requires physical effort to open and close, ensuring straightforward operation for users. The simple design also provides enhanced durability and ease of maintenance compared to automated door mechanisms.

Q: What safety features are included in the elevator's design?

A: The elevator comes equipped with an emergency stop button, overload protection, emergency alarm, and an auto rescue device. There is also an optional infrared sensor for the door, which prevents accidental door closure while someone is entering or exiting the cabin.

Q: When should periodic maintenance be performed and what does it involve?

A: Periodic maintenance should be conducted every three to six months to keep the elevator in optimum condition. Maintenance involves lubrication of moving parts, inspecting the guide rails, servicing the control panel, and checking the emergency systems.

Q: Where is this manual door passenger elevator commonly installed?

A: This elevator type is ideal for residential buildings, low- to mid-rise commercial complexes, and spaces where moderate passenger traffic is expected. Its flexible dimensions and manual mechanism suit a variety of site conditions typically found in India.

Q: What are the primary benefits of choosing a manual door elevator with LED/LCD floor display?

A: Benefits include lower maintenance costs due to the simple door mechanism, enhanced visibility and aesthetics from the digital display, greater energy efficiency with LED lighting, and reliable operation provided by microprocessor-based controls.

Q: How does the auto leveling feature improve passenger safety and convenience?

A: Auto leveling ensures the cabin stops precisely level with the floor at each landing. This minimizes trip hazards, eases loading and unloading, and is particularly beneficial for those with mobility challenges.
